Front View Back View

PJK-10-M Features : 1.      10.4” LCD with optical bonding technology. 2.      DDR 266/200 SO-DIMM memory up to 2GB 3.      Rugged Design for Harsh Environments 4.      CRT/LCD VGA integrated in i852GM 5.      Support Gigabit Ethernet 6.      All housing Aluminum Alloy 6061-T6 design 7.      Housing safety angle design Description LCD Size 10.4" Max Resolution 800 * 600 Brightness (cd/㎡) 400 Contrast Ratio 500:1 LCD Color 262K Pixel Pitch (mm) 0.264 (H) x 0.264 (V) Viewing Angle (H-V) 160° / 140° Backlight MTBF 50000 hrs SBC Model ABORN-GSE-N270-R10 CPU Intel® Atom™ process N270 1.6GHz CPU Chipset Intel 945GSE / ICH7M RAM Supports one 400MHz or 533MHz DDRII SO-DIM (2GB Max.) Standard shipping 1GB memory. I/O Ports ( military connector) 2 x RS-232 COM Port ( Full 9 pin x 1 /. RXD,TXD,GND x 1 ) 1 x RS-232/422/485 COM port 1 x RJ-45 for Giga LAN 1 x USB 2.0 SSD 8G ~128G ( price will be different ) Watchdog Timer Software programmable supports 1~255 sec. System reset Brief keyboard on front panel ESC/ F1 / F2 / F3 / F4 / F5/ UP/ DOWN/ LEFT/ RIGHT/ ENTER Construction Material All housing Aluminum alloy 6061-T6 Mounting device Optional LED Function 1 x for Power ON/OFF and 1 x for HDD Front Panel Color Army Green Dimension (WxHxD) (mm) See drawing below Operation Temperature -30°C~60°C Storage Temperature (℃) -40°C~65°C Net Weight 4.85 Kg IP Level IP64 Touch Screen ( OPTIONAL ) Resistive Type Power Adapter Input: 90VAC~264VAC, 50/60Hz Output: 21VDC Power Input 18~32VDC Power Consumption 28W
